Automated conveyor systems for your warehouse
Skypath
Skypath® is a disruptive plug-and-play automated conveyor system that consists of straight, curved, and inclined building blocks that cover most clients’ needs.
Thanks to the signature modular design, the Skypath can be deployed in weeks, without complex hardware integration and with minimal interference to ongoing operations.
Easy to scale
Modular and pre-programmed conveyors meant to reduce the installation and set-up time.
Quick to install
Controls are 100% API based and do not require on-site controller programming.
Highly efficient
Up to 2,700 bins/h and 72 meters/min (236 ft/min).
Plug & Play
Skypath comes pre-wired and requires no PLC programming on-site. The embedded software helps identify the conveyor layout, drastically improving the installation speed. 500 meters (1,640 feet) of conveyors can be installed in less than 200 hours.
Performance guaranteed
Powered by software and elegant engineering, the conveyors can reach a maximum throughput of 2,600 totes per hour and a speed of up to 72 meters per minute (236 feet per minute). The built-in sensors and 24/7/365 support ensure fast diagnostics and remote intervention, minimizing downtime.
Scales to customer needs
With a modular design that consists of straight, curved, and inclined building blocks, Skypath fits the vast majority of logistic needs and warehouse layouts. The automated conveyor system can be easily modified to adapt to rapidly changing customer needs.
Conveyor Section Types
Straight
Curve
Transfer Table
| Specifications | |
|---|---|
| Section Types | Straights, 45° Curves, Transfer Tables |
| Coating Type | Steel or PVC coated roller, Belt Over Roller |
| Conveyor Widths | 512mm or 712 mm (20.15 to 28.03 in) |
| Conveyor Lengths | 180mm to 2700mm (7.08 to 106.29 in) – for 512mm wide – Adjustable to the nearest mm 180mm to 2025mm (7.08 to 79.72 in) – for 712mm wide – Adjustable to the nearest mm |
| Conveyor Heights | Up to 3 Conveying Levels – Max Height of 4500 mm (177.16 in) |
| Standards Accessories | Barcode Readers, Safety Status Light, Emergency Stops, Reset Button |
| Speed | Up to 72 m/min (236.22 fpm) |
| Capacity | Up to 2,600 totes/hour (Straight & Curves – PVC/Steel) Up to 1,400 totes/hour (Belts and 90° Transfer Tables) |
| Slopes | Up to 12° |
Frequently Asked Questions
Can Skypath be purchased independently from the Skypod system?
No, Skypath is an integral component of the Skypod system and cannot be purchased independently.
Does Skypath integrate with automation beyond the Skypod system?
Absolutely, Skypath is not just limited to integration with the Skypod system. It is a highly flexible solution engineered to work with a wide range of warehouse automation technologies. A key feature of Skypath is its capacity for automatic integrations with the majority of API-based warehouse management systems. This capability ensures that Skypath can seamlessly connect with various existing systems, enhancing its utility and effectiveness in diverse operational environments.
What are the benefits and differentiating features of Skypath compared to other automated conveyor systems?
Skypath offers several key advantages over traditional automated conveyor systems:
- Ease of Installation: The pre-wired system simplifies the installation process. This eliminates the need for complex on-site PLC programming, reducing setup time and technical hurdles.
- Flexibility: Skypath’s modular design not only expedites installation but also ensures that the system can be easily scaled up or modified as needed, making it an ideal choice for evolving warehouse environments.
- Seamless Integration: Specifically engineered to integrate with the Skypod system and other warehouse automation technologies, Skypath enhances overall efficiency and coordination within the warehouse.
What is the installation process for Skypath?
The Skypath installation process is designed to be efficient, minimally disruptive, and expedient, with several key aspects ensuring a smooth implementation:
- Minimal Hardware Installation: The process is designed to minimize hardware installation requirements, thereby preventing significant disruption to ongoing operations at the site. This approach allows for a quicker setup and integration into existing warehouse activities.
- Embedded Software Assistance: Skypath has embedded software that plays a crucial role in identifying the optimal conveyor layout. This technology greatly speeds up the installation process by providing precise guidance on setup and configuration tailored to the specific needs of the warehouse environment.
- Modular Design: The inherent modular design of Skypath further facilitates a faster and more adaptable installation. This allows for quick adaptation to the evolving needs of warehouse operations and enables easier scaling in the future.
Together, these factors ensure that the installation of Skypath is a streamlined process, aligning with the operational tempo of modern warehouses and reducing downtime.
What considerations should I keep in mind when integrating conveyor systems into my warehouse environment?
When integrating automated conveyor systems like Skypath into your warehouse, it’s essential to consider the following:
- Operational Needs: Assess the volume, types of goods, and throughput requirements to ensure the conveyor system can meet these demands.
- Space Constraints: Evaluate the available space and layout of your warehouse to determine how the conveyor system can be optimally configured.
- Integration with Existing Systems: Ensure that the conveyor system can seamlessly integrate with existing warehouse management systems and other automation technologies like the Skypod system.
- Budget: Determine your budgetary constraints considering the upfront investment and the long-term operational savings.
- Scalability: Assess the scalability of the conveyor system to ensure it can grow alongside your evolving operational needs.
- Maintenance and Support: Consider the level of maintenance required and the support provided by the vendor.
